Vacuum Interrupter for Capacitor Switches

The state of the art vacuum interrupter for capacitor switches manufacturing facility of 12 kV & 36 kV class for use in vacuum switchgear, consists of ultra clean rooms of class 100 and vacuum processing furnaces etc., with complete test facilities.

Technical Parameters:

Description

Rated Voltage
Rated Current
Insulation Level
Power frequency withstand voltage
Impulse withstand voltage
Rated short time withstand current
Rated short circuit breaking current
Rated duration of short circuit
Rated operating duty circle
Contact Life
Mechanical
At load Current
At full short circuit

Up to 36 kV rms
Up to 2500 A

Up to 70 kV rms
Up to 170 kV peak
Up to 40 kA rms
Up to 40 kA rms
3 sec
O-0.3 sec-CO-3min-CO

30,000 operations
20,000-30,000 operations
100 operations

TF412U VITF 27/200U: Vacuum Interrupter For Capacitor Switches that we offer are required in diverse industrial units. Our Vacuum Interrupter For Capacitor Switches need low maintenance and can with stand extreme conditions easily. Vacuum Interrupter For Capacitor Switches, provided by us, are safe to use and have longer working life.
Read More

TC410G VITC 27/200G: We are reckoned as noteworthy Exporter and Supplier of Vacuum Interrupter For Capacitor Switches in Uttar Pradesh. Our Vacuum Interrupter For Capacitor Switches are highly reliable and efficient.
Read More

TC310G VITC 15/200G: We provide premium Vacuum Interrupter For Capacitor Switches that in compliance with high industrial standards. Vacuum Interrupter For Capacitor Switches, offered by us, can easily perform numerous electrical and mechanical operations our quality auditors.
Read More

TC420S VITC 24/400S: Vacuum Interrupter For Capacitor Switches that we provide have longer shelf life and can perform more number of electrical as well as mechanical operations than other products in the market. Along with good electrical endurance, our Vacuum Interrupter For Capacitor Switches are very efficient.
